Item No :
YT-5096-R1Sensor :
1/4(640*480 5.6um)F/NO. :
F2.7EFL :
2.3mmOptical TTL :
12.98mmThread Size :
M8 mount LensFOV(H/V/D) :
100 degree/80 degree/170 degreeStructure :
1G2P+IR Filter
YT-5096-R1: The Ultimate Rearview Companion for Safe Driving
know more about YT-5096-R1 Car Rear View Camera Lens parameters | |
MAX Img-Circle( mm) | ∅5.20 |
EFL( mm) | 2.3 |
F/NO | 2.7 |
Optical TTL | 12.98mm |
BACK FOCAL LENGTH | 5.24mm |
FLANGE BACK LENGTH | 2.15mm |
Sensor |
1/4(640*480 5.6um) |
A Clear View for Enhanced Safety
The YT-5096-R1 car rearview lens is designed to provide an unparalleled rearview experience for vehicles. With an optical focal length (EFL) of 2.3mm and a total length (TTL) of 12.98mm, this lens offers a wide field of vision that is essential for safe driving and parking. The Back Focal Length (BFL) of 5.24mm ensures precise image projection.
Ultra-Wide Field of View for Comprehensive Coverage
The YT-5096-R1 rear view lens is tailored to match a 1/4'' inch CMOS sensor, delivering a 170-degree diagonal field of view (Dfov), a 100-degree horizontal field of view (Hfov), and an 80° vertical angle. This ultra-wide coverage ensures that the driver has a complete view of the area behind the vehicle, reducing blind spots and enhancing safety.
F/NO2.7 Aperture for Reliable Visibility in Various Lighting Conditions
Equipped with an F/NO2.7 aperture, the YT-5096-R1 rearview lens ensures clear visibility in a range of lighting conditions. This feature is crucial for maintaining a clear view of the road and surroundings, day or night, ensuring that drivers have the confidence to make safe maneuvers.
Customizable Mounting Options for Seamless Integration
The car rear view lens features an M8 mount lens, with a front cover diameter of 12mm, offering a secure and standardized connection to various camera systems. It can be customized to an M12 mount according to specific project requirements, ensuring adaptability for different automotive applications.
Durable Metal Housing with Advanced Optical Technology
The YT-5096-R1 Parking Assist System lens is encased in a robust metal barrel, showcasing its high-quality build. It includes a 650nm IR filter, enhancing the lens's performance in various lighting conditions and ensuring clear and vibrant images.
Rugged and Reliable for All Weather Conditions
With an IP67 rating for water and dust resistance and TS16949 certification, the YT-5096-R1 car reverse assistance lens is built to withstand the harshest environments. It operates reliably in temperatures ranging from -40℃ to +85℃, making it suitable for all weather conditions.
Versatile Applications Beyond Rearview Monitoring
The YT-5096-R1 car rear view lens's utility extends beyond rearview monitoring. It is suitable for a multitude of applications, including passenger monitoring, driver monitoring, cabin surveillance, electronic rearview mirrors, streaming rearview mirrors, action cameras, handheld gimbals, drones, intelligent robot cameras, AI cameras, consumer electronics, USB high-definition cameras, AI robot surveillance cameras, video conferencing cameras, smart home monitoring, USB surveillance, IP cameras, and facial recognition cameras.
In Summary
The YT-5096-R1 car rear view lens is the epitome of automotive rearview lens technology, offering a combination of ultra-wide field of view, reliable visibility in various lighting conditions, and durable construction. Its advanced features make it an indispensable tool for vehicle safety and a wide range of imaging applications. Experience the versatility and excellence of the YT-5096-R1, ensuring comprehensive surveillance and enhanced safety on the road.
In the world of optics, web searches are no substitute for our direct, comprehensive, customer-tailored application assistance. Send specific requirements email (lina@yuntal.com) to have a professional lens application engineer contact you for personal assistance.
Our lens specification include: AA lens,M12*P0.5 lens, M10*P0.5 lens, M9*P0.5 lens,M8*P0.5 lens, M7*P0.35 lens, 2 megapixel lens, 3 megapixel lens, 5 megapixel lens, 12 megapixel lens, 14 megapixel lens, 16 megapixel lens,low distortion lens,zero distortion lens,F1.6 Lens, F2.0 lens,F2.2 lens, F2.4 lens, F2.5 lens, F2.8 lens....Support Customized Lenses!
