Item No :
YT-1537P-I1Sensor :
1/3 JX-H63F/NO. :
2.8EFL :
2.36Optical TTL :
8Thread Size :
M7*P0.35FOV(H/V/D) :
75°/88°/47°Structure :
/
YT-1537P-I1: The Bespoke Optic for Versatile Imaging Solutions
| know more about YT-1537P-I1 Customized Lens parameters | |
| MAX Img-Circle( mm) | ∅5.10 |
| EFL（ mm） | 2.36 |
| F/NO | 2.8 |
| Optical TTL | 8mm |
| BACK FOCAL LENGTH | 2.46 |
| FLANGE BACK LENGTH | 1.25 |
| TV DISTORTION | ＜-18.38% |
| CRA | 20.7° |
| Recent Camera Distance |
0.2 |
| WAVELENGTH |
@420~600nm Tavg≥90% @650±10nm T=50% |
| Sensor |
1/3'' JX-H63 |
Precision Customization for Diverse Applications
The YT-1537P-I1 customized lens is a custom camera lens that caters to the unique demands of various imaging applications. With a 2.36mm optical focal length and an 8mm optical total length, this lens is meticulously engineered to deliver exceptional performance in a compact form factor.
Optimal Imaging with 1/3" CMOS Sensor Compatibility
Designed to match the 1/3" inch CMOS sensor JX-H63, the YT-1537P-I1 customized lens achieves 1mp resolution, ensuring high-resolution imaging. The customized lens offers a field of view with an 88° diagonal dfov, 75° horizontal hfov, and 47° vertical angle, coupled with minimal distortion of less than -18%. The maximum lens imaging circle diameter of 5.1mm guarantees edge-to-edge clarity.
Versatile Aperture for Diverse Lighting Conditions
Equipped with an F/NO.2.8 aperture, the YT-1537P-I1 customized m7 mount lens is versatile and performs well across different lighting environments. This feature makes it suitable for a wide range of applications where lighting conditions may vary.
Customizable Interface to Meet Specific Requirements
The lens features a standard M7*P0.35 thread lens, ensuring compatibility with various camera systems. The lens end cap diameter is 8mm, and the interface can be customized according to client needs, providing flexibility for diverse integrations.
Innovative Construction for Enhanced Performance
The YT-1537P-I1 m7 lens is housed in a robust plastic barrel and adopts a hybrid glass-plastic 2G2P structure, along with an 650nm wavelength IR filter. This advanced construction results in excellent MTF performance and reliability. The lens offers high transmittance (greater than 90%) in the 420~620nm spectral band, ensuring clear and vibrant images.
Extensive Applications in Diverse Fields
The YT-1537P-I1 customized lens is not limited to a single application. Its versatility makes it suitable for a multitude of uses, including vehicle dash camera lens, car camcorder Lens,rearview camera lens, surround view camera lens, front and side surveillance camera lens, AI robot monitoring camera lens, video conference camera lens, smart home monitoring lens, USB surveillance lens, IP camera lens, and facial recognition camera lens.
In Summary
The YT-1537P-I1 m7 lens is a custom lens that embodies the spirit of innovation and precision. Its optimal imaging capabilities, versatile aperture, customizable interface, and innovative construction make it an ideal choice for a wide range of imaging applications. Experience the adaptability and excellence of the YT-1537P-I1 customized lens, a lens that is designed to meet the specific needs of your vision.
