Item No :
YT-1709-N1Sensor :
1/2.9(1920*1080 2.8um)F/NO. :
2.8EFL :
3.2mmOptical TTL :
15.4mmThread Size :
M8*P0.5 mount(Support Customized M12 Mount Lens)FOV(H/V/D) :
105°/54°/126°Structure :
4E with IR filter
YT-1709-N1: The Clarity of Vision for Your Drive On Traffic Road
know more about YT-1709-N1 Car Driving Recorder Camera Lenses parameters | |
Sensor Circle(mm) | SC200AI(1920*1080) |
Focal Length(EFL) | 3.2mm |
F/NO.(Infinite) | F2.8 |
Optical TTL | 15.08mm |
Back Focal Length | 5.29mm |
Flange Back Length | 4.49mm |
TV Distortion | -25% |
Thread Size | M8*P0.5 Mount |
Precision Engineering for Clear Road Capture
The YT-1709-N1 driving recorder lens is a testament to precision engineering, offering an optical focal length (EFL) of 3.2mm and a total length (TTL) of 15.8mm. With a Back Focal Length (BFL) of 5.29mm, this lens is designed to capture the road ahead with clarity and detail.
Wide-Angle Coverage for Comprehensive Surveillance
Featuring a diagonal field of view (Dfov) of 126 degrees, a horizontal field of view (Hfov) of 105 degrees, and a vertical angle of 54°, the YT-1709-N1 dashcam dual-lenses ensure that your vehicle's surroundings are fully within sight. The maximum imaging circle diameter of 7.0mm allows for extensive coverage, making this lens ideal for a wide range of driving conditions.
F/NO2.8 Aperture for High-Definition Imaging
Equipped with an F/NO2.8 aperture, the YT-1709-N1 video recorder lens delivers high-definition 4MP imaging, providing clear and detailed captures of the road conditions. This wifi GPS auto camera lens is designed to perform exceptionally well in various lighting environments, ensuring reliable recording quality at all times.
Customizable Mounting Options for Seamless Integration
The car dvr lens comes with an M8*P0.5 mount lens, and the front cover diameter is 10mm, offering a secure and standardized connection to driving recorder systems. It can be customized to M7, M9, M10, or M12 mounts according to specific project requirements, ensuring adaptability for different automotive applications.
Durable Metal Housing with Low Distortion
The YT-1709-N1 dashboard camera lens is encased in a robust metal barrel, showcasing its high-quality build. With -25% distortion, it is considered a low-distortion lens, which is crucial for accurate and reliable recording in various driving conditions. The car dvr lens is composed of four glass lenses, ensuring durability and optical performance.
Versatile Applications Across Diverse Fields
The YT-1709-N1 car camera lens's utility extends beyond driving recorders. It is suitable for backup cameras, passenger monitoring, driver monitoring, cabin surveillance, electronic rearview mirrors, streaming rearview mirrors, action cameras, handheld gimbals, drones, intelligent robot cameras, AI cameras, consumer electronics, USB high-definition cameras, AI robot surveillance cameras, video conferencing cameras, smart home monitoring, USB surveillance, IP cameras, and facial recognition cameras.
In Summary
The YT-1709-N1 driving recorder lens is the epitome of automotive lens technology, offering a combination of high-definition imaging, a wide-angle field of view, and durable construction. Its advanced features make it an indispensable tool for vehicle safety and a wide range of imaging applications. Experience the versatility and excellence of the YT-1709-N1, ensuring that every journey is well-documented and secure.
