Item No :
YT-7600-K4Sensor :
SC233ATF/NO. :
2.4EFL :
2.2mmOptical TTL :
17.08mmThread Size :
AA Gluing LensFOV(H/V/D) :
152°/86°/178°Structure :
6E+1IRYT-7600-K4: The High Definition Guardian for In-Cabin Surveillance
know more about YT-7600-K4 Car OMS Camera Lens parameters |
||||
Img-Circle( mm) | ∅6.72 | |||
EFL( mm) | 2.2 mm | |||
F/NO. | 2.4 | |||
Optical TTL | 17.08 | |||
Mechanical TTL | 17.08 | |||
BACK FOCAL LENGTH | 4.70 | |||
FLANGE BACK LENGTH | 3.02 | |||
TV DISTORTION | <-33% | |||
RELATIVE ILLUMINATION | >75% | |||
CRA | 16° | |||
Pixel Size (μm) | 3.0um*3.0um | |||
Storage At Temperature | -40℃~+85℃ | |||
Recent Camera Distance | 0.2 | |||
Infrared | Non-infrared | |||
WAVELENGTH | @425~635nm Tavg≥90% @940nm±10nm T≥80% |
|||
Dust Level | IPX7 | |||
STRUCTURE |
6E+1IR filter |
Omnipresent Clarity with Ultra-Wide Angle
The YT-7600-K4 OMS lens is a pioneering passenger/ occupant monitoring lens designed for the automotive industry, featuring an ultra-wide field of view with an optical focal length (EFL) of 2.2mm and a compact total length (TTL) of 17.08mm, including a Back Focal Length (BFL) of 4.7mm. This OMS lens covers a staggering 178-degree diagonal field of view (Dfov), ensuring that every corner of the cabin is within sight.
High-Definition Imaging for Unparalleled Surveillance
Equipped to match the CMOS sensor SC233AT, the YT-7600-K4 OMS lens achieves a 5mp high-definition resolution, providing clear and detailed imagery for in-cabin surveillance. With a horizontal field of view (Hfov) of 152 degrees,Dfov 178 degree and a vertical angle of 86°, this car camera lens captures a comprehensive view of the cabin, and it is compatible with a range of chips such as ISX031, IMX623, IMX390, and OX03C.
F/NO2.4 Aperture for Reliable Visibility in Any Light
The Occupancy Monitoring System lens features an F/NO2.4 aperture, ensuring reliable visibility in various lighting conditions. This ensures that the lens performs exceptionally well, providing clear images for monitoring purposes, which is crucial for maintaining safety and awareness within the vehicle.
Customizable Mounting Solutions for Seamless Integration
With an AA Gluing lens interface and a front cover diameter of 14mm, the YT-7600-K4 OMS lens can also be customized to an M12 mount lens according to specific customer project requirements. This flexibility allows for easy integration with a variety of in-cabin camera systems.
Durable Construction with Advanced Optical Technology
The YT-7600-K4 OMS lens is encased in a robust aluminium lens barrel, showcasing its high-quality build. It utilizes a full-glass lens structure and includes a 940nm dual-pass IR filter, ensuring excellent MTF performance and reliability. This advanced lens technology provides clear and vibrant images in all driving conditions.
Rugged and Reliable for Extreme Conditions
With an IPX7 rating for water and dust resistance and TS16949 certification, the YT-7600-K4 OMS lens is built to withstand the harshest environments. It operates reliably in temperatures ranging from -40℃ to +85℃, making it a dependable choice for all weather conditions.
Versatile Applications for Extended Utility
The YT-7600-K4 car camera lens's utility extends beyond Occupancy Monitoring System(OMS). It is suitable for a multitude of applications, including driver monitoring, cabin surveillance, electronic rearview mirrors, streaming rearview mirrors, action cameras, handheld gimbals, drones, intelligent robot cameras, AI cameras, consumer electronics, USB high-definition cameras, AI robot surveillance cameras, video conferencing cameras, smart home monitoring, USB surveillance, IP cameras, and facial recognition cameras.
Successfully Implemented in AITO M9 Vehicles
The YT-7600-K4 OMS lens has been successfully integrated into AITO M9 vehicles, showcasing its reliability and performance in real-world applications.
In Summary
The YT-7600-K4 is the epitome of automotive passenger monitoring technology, offering a combination of high-definition imaging, an ultra-wide field of view, and reliable visibility in any light. Its durable construction and advanced features make it an indispensable tool for in-cabin safety and a wide range of imaging applications. Experience the versatility and excellence of the YT-7600-K4, ensuring comprehensive surveillance and enhanced safety within the vehicle.
