DMS lenses CMS lenses for Vehicle Monitoring Camera System YT-7620-A8

Revolutionize Your Driving Safety with the YT-7620P-A8 CMS Lens DMS Lenses

Application: Automotive monitoring camera system, car surround view camera lenses, car rearview camera lenses, car dvr / driving recorder camera lenses, DMS camera lenses, OMS camera lenses, CMS camera lenses, ADAS camera lenses, board camera lenses, security monitoring, vehicle monitor, sports DV camera, FPV aerial photo, panorama camera, fisheye camera lens, recorder for law enforcement, AR/VR camera, smart home surveillance camera lens, scanner, video conference camera lenses, face recognition video door bell etc used in optical field.

Unmatched Night Vision

The YT-7620P-A8 DMS lens is a testament to Wintop Optics' commitment to clarity and safety. Designed for applications such as electronic rearview mirror cameras and in-cabin driver fatigue monitoring etc. this lens features an F2.2 aperture that harnesses advanced optical technology. It ensures clear, well-balanced imagery even in low-light conditions, making nighttime travel as safe as day.

Precision Engineering

This sophisticated DMS lens / CMS lens boasts a 4.15mm optical focal length and a mechanical length of 21.17mm, with a 14mm head diameter. The standard M12*P0.5 thread structure and sleek design not only provide a refined appearance but also guarantee seamless integration with various camera systems. The inclusion of automatic focus technology ensures that every frame is perpetually crisp and clear.

High-Definition Imaging

With a chip output of 1920*1536, the YT-7620P-A8 DMS lens / CMS lens delivers five million pixels of high-definition clarity. This DMS lens / CMS lens captures imagery with a diagonal angle of 67 degrees, a horizontal angle of 51 degrees, and a vertical angle of 41 degrees. The result is a richly detailed, high-resolution image that leaves nothing to the imagination, with a lens image height of 7.2mm for optimal clarity.

Low Distortion Lens for Accurate Views

The YT-7620P-A8 DMS lens / CMS lens is crafted with a low distortion rate of less than 8%, ensuring that the images it captures are true to life and free from unwanted visual anomalies.

Rugged and Resilient

Wintop Optics understands the demands of the road. That's why the YT-7620P-A8 DMS lens / CMS lens is built to withstand the elements, with an IP69k rating for waterproof and dustproof performance. It operates reliably in temperatures ranging from -40℃ to +85℃, ensuring consistent operation in all climates. Plus, it carries the IATF16949 certification, a mark of quality and reliability.

Enhanced Visual Clarity with Blue Glass Filter

Equipped with a blue glass filter, the YT-7620P-A8 DMS lens / CMS lens offers more than 90% light transmission in the 420~600nm spectral band. This feature significantly reduces glare and chromatic aberration, ensuring that Driver Monitoring camera System / Camera Monitoring System Lens captures clear, vibrant images without distortion.

Choose the YT-7620P-A8 DMS lens / CMS lens for a Driving Experience That's Ahead of the Curve

With Wintop Optics, you're choosing a partner dedicated to innovation and excellence in automotive imaging. Experience the future of driving vision with the YT-7620P-A8 DMS lens / CMS lens– where clarity, durability, and precision meet. Drive confidently, knowing that every aspect of your journey is captured with the utmost clarity and reliability.
