Auto Parts 1/4 "Small Angle -8% Low Distortion M12 for Vehicle Panorama YT-6031-A8

  • 6Gstructural composition
  • 15.21optical length
  • Item No :

    YT-6031-A8
  • Sensor :

    1/4''
  • F/NO. :

    2.4
  • EFL :

    1.51
  • Optical TTL :

    15.21
  • Thread Size :

    M12
  • FOV(H/V/D) :

    76/46/94
  • Structure :

    6G

YT-6031-A8: Exploring the unknown at a glance

know more about YT-6031-A8 Automotive Lens parameters
EFL( mm) 1.51
F/NO. 2.4
Optical TTL 15.21mm
BACK FOCAL LENGTH 3.44mm
FLANGE BACK LENGTH 2.24mm
TV DISTORTION -8%
RELATIVE ILLUMINATION 65%
CRA 13°
Storage At Temperature -40℃~+85℃
Dust Level IP67
STRUCTURE 6G



Carefully designed : bring you an experience beyond the ordinary horizon. YT-6031-A8 is a panoramic lens specially designed for the automotive sector, conquering the market with its excellent functions and unlimited potential.

Exceptional field of view: Equipped with a 1/4-inch sensor, the YT-6031-A8 has an amazing field of view. It achieves a diagonal angle of 94 °, a horizontal angle of 76 °, and a vertical angle of 46 °, allowing you to grasp everything in front of you with unparalleled clarity. Whether it is driving safety or driving experience, it will be fully enhanced by its competence.

High-quality imaging: The focal length of YT-6031-A8 is 1.51mm and the aperture is 2.4, which gives full play to the advanced optical technology of Yunding Optics. It presents you with real, clear and delicate images, making every frame full of vitality. More professionally, the TV distortion value is only -8%, which greatly reduces the distortion of the image and allows you to feel more accurate visual feedback.

Powerful structure: YT-6031-A8 adopts M12 * 0.5 screw structure and 6G lens group to ensure its strong and reliable performance. Whether it is harsh road environment or extreme temperature changes, it can work stably and last for a long time. In the constantly bumpy journey, Yunding Optical lens always guards your safety.



The YT-6031-A8 is a leader in the field of vehicle panoramic lenses. It not only has an excellent field of view and excellent imaging quality, but also has a rugged construction to provide you with all-round protection. Whether you are a driving enthusiast or looking for a more intelligent driving experience, the YT-6031-A8 will become an indispensable partner in your driving journey.
